Made in accordance to the guideline 2006/42/EG and is labelled with the CE sign.
REAR DOOR
The rear door is locked and unlocked, opened and closed hydraulically. A
unlatch safety valve secures the rear door when raised against its
accidental fall down, regarding to the German UVV safety regulations. In
order to separate the waste water from the solid part of the debris, there
is a large filter grid at the inside part of the rear door connected to the
outside through a drain adapter and a drainage flexible pipe.
TRANSMISSION
Using four V-Belts, the suction fan is directly connected to the drive shaft of the auxiliary engine. Additionally, a hydraulic pump for the drive of the secondary functions, like brushes and hopper tipping system is driven over the same v-belts.
AIR RECYCLING SYSTEM
The FAUN air recycling system is recirculating up to 70% (adjustable) of the suction fan exhaust air and reusing it through a flexible hose in the blowing nozzle. The rest of the exhaust air will be decelerated in the air stilling chamber and sinks under the vehicle out to the environment. The high rated heavy-duty suction fan, adapted for the FAUN air recycling system is made of high wear resistant steel.
BODY
Emptying of the body is controlled over the switches on the control panel in the cab (open the rear door and tilting the hopper). Following the UVV standard prescriptions the closing of the rear door can only be made from the tail of the sweeper.
